Sealing Machines

The Multivac R230 is suitable for thermoforming and packing a wide variety of meat, poultry, pork, cheese, sliced meats and cooked products and is a great addition to any wholesale butcher, food processor or industrial manufacturer. 2 die sets: - 1 set for stick packs - 1 for large pork trays. - Mold dimensions: Die 1: 2 across large die layout Die produce a 235mm x 150mm pack. Forming box d

Single handle height adjustment Mobile on castors Electrics: 1~, 220V, 50Hz Belt width: 155mm Belt length:1000mm CBS-1100V Power Supply/Voltage 220V 50Hz/60Hz Single Phases Power Consumption 1200W Sealing Speed 0-15m/min Sealing Width: 5-10mm Sealing Film Thickness 0.02-0.8mm Temperature Range 0-300

Newlong Stitching machine: Specifications: Speed: 2700pins/min Pin Distance: 7-11.5mm (standard 10mm) Max Sewing Material Thickness: 8mm Pin: DR-H30#26 Thread Model: Dual-Line Thread Spec: 20s/6; 20s/9 fiber thread Lubricating Model: Total sealing (suggest Mobil Oil 32#) Thread Cut Model: Pneumatic Motor Model: Electromagnetism drive Power: 0.75KW Voltage: Three-Phase, 415V, 50Hz Frame: SUS304 S

Mondini CVS/VG Tray Sealer High Speed Single Lane Tray Sealer High throughput and operator friendly. Model: CVS/VG.1-S Project No: 2020-02/1 Manufacturing date: 07/11/02 Voltage: 415 Phase: 3+N Frequency: 50Hz Electrical drawing number: SE2785/Z <b>TBC</b> Tray Application Method: Pre-Formed Tray Length: 195 Tray Width: 155 Product Pick-up Method: Vacuum Dimensions: 3700mm L x 1000mm W x 2150mm

Comadis C-130 tube filler. All stainless steel construction. Maximum filling speed 50 tubes per minute. Hot air sealing technology for plastic tubes. One hour changeover time between heads. E Rotary valve piston. Auto cassette infeed. Large product hopper with agitator for viscous products. Mobile on wheels. Machine size: 1800mm x 800mm x 1750mm high, weight 1000kg Options: - 6 sets of change par

Sealing range 20~60mm. Sealing head: 500×200×103mm. Electric specification: 1. Voltage：AC230V+8% 2. Frequency：50/60HZ 3. Max. power：3000W 4. Main pars：IGBT 5. Interior oscillatory frequency：35KHZ 6. Radiator：air-cooled 7. The length of power cord ：over 5 meter 8. PC board：the mode of exchange 9. Temperature of the position on operation：-10℃~ +45℃ 10. Max. electric current：12A Essential data o

Conveyer Size: 110 x 630 mm Sealing Direction:From Left to Right Bag Length Range: 50 - 280 mm Table Top Speed: 5-12 m/min Vertical Sealing width: 10mm Stainless Steel Body OMRON Temp. Controller Voltage: Single-Phase, 240V, 50Hz

Speed: 0.7 – 0.8 m/min (Adjustable Speed) Sealing Width: 10 mm Sealing Height: 750 – 1,450 mm off Ground (Adjustable Height) Temperature Range: 0 – 300 Degrees C (Adjustable) Power Consumption: 7.5 kW Air Pressure: 0.6 MPa Controls: HMI/PLC Also Available in Stainless Steel Construction at Additional Cost.

<Specifications> Sealing Speed: 0 - 12 m/min Sealing Width: 10 mm Sealing Head Height: 1,600 mm - Custom-Made (Auto Adjustment) Power: 1-Phase, 240V, 50Hz Flow Direction: Left to Right Max Weight for Conveyor: 50 Kg Side Guide Rails x 2: Included Price is subject to confirmation of project scope.

Very neat, compact machine! Crosscutting is zigzag guillotine. Max Film Width: 400 mm Max Pitch: 180 mm Max Tray Depth: 40 mm Bottom Film Max Core Diameter: 250 mm Lidding Film Max Core Diameter: 250 mm YOM 2010 Electrics: 3 phase, 415 Volts, 20 Amps, 50Hz Total Power~ 6.8kW, Consumption: 20A Year of Manufacture 2010.

Multivac, Inc. Fully Automatic Tray Sealer T 350 Throughput : Up to 36 trays per min (up to 12 cpm) Tray Size: 420 x 300 mm Tray Height max : 110 mm Electrics: 3-Phase, 415V, 50Hz, 30.5 A. This is MULTIVACS smallest fully automatic traysealer packages up to a maximum of 36 packs (12 cycles) per minute. The T350 is suitable for food and sterile medical products as well as technical products

This pull out type tray sealer was used in a ready-meals manufacturing plant. Set up currently for 2 x ovoid shaped products per tray, each 175mm long by 110mm at the middle point. Electrics:415V, 3 Phase, 20 Amps, 5 pin plug, 50Hz Motor: 0.35kW Dimensions: 1,150 x 1,000 x 1,600mm (l x w x h)

* Machine caters for tray size up to 180 mm x 220 mm The machine has platens for a tray approx 160 x 115mm There are no other change parts. * Suitable for any sealable trays such as PP. PE. PET. PVC. and Card Board trays. * Sealing jig with film seal, cut and rewind device * Machine throughput: Approx 18 cycle/minute (product and size dependent) * Machine controlled by PLC. through Touch

<Specifications> Stainless Steel Frame Sealing Speed: 7 m/min Sealing Width: 10 ㎜ Power: 1-Phase, 240V, 50HZ Flow Direction: Left to Right Max Weight for Conveyor: Up to 10 Kg Bag Height: 100 mm - 800mm IP54

<Specifications> Sealing Speed: 0 - 12 m/min (Variable Speed) Sealing Width: 10 mm Power: 1-Phase, 240V, 50HZ Flow Direction: Left to Right Max Weight for Conveyor: Up to 10 Kg Bag Height: 100 - 800 mm

<Specifications> Seal Length: 600 mm Seal Width: 8mm Sealing Time: 1 - 8 sec Bag Size: 600 W x 850 H mm (Adjustable Frame to Suit Bag Height) Bag Materials: PE, PP, Poly-Line Bags Power: 1,800 W Air Consumption: 6 - 8 Kg/sqcm Power Supply: 1-Phase, 240V, 50Hz Material Constructions: SUS304 (Frame), Aluminium (Head)

Specifications: Speed: 2700pins/min Pin Distance: 7-11.5mm (standard 10mm) Max Sewing Material Thickness: 8mm Pin: DR-H30#26 Thread Model: Dual-Line Thread Spec: 20s/6; 20s/9 fiber thread Lubricating Model: Total sealing (suggest Mobil Oil 32#) Thread Cut Model: Pneumatic Motor Model: Electromagnetism drive Power: 0.75KW Voltage: Three-Phase, 415V, 50Hz Frame: SUS304

Mondini semi-automatic heat sealers are available in "heatseal only" or "heatseal with vacuum flush". Construction is simple, functional and high quality, with a flexible choice of tray size and the possibility to seal one or more trays at a time. Quick change-over, approximately 5 minutes, automatic film feed, adjustable gas and vacuum times. Speed - 4-5 cycles per minute including gas or vacu

The IOPAK CLIP-QDK4 pneumatic single clipper is made of stainless steel and uses a U-shape aluminium card. It is powered by pressurized air. Pneumatic) 1. Features: 1) Simple operation 2) Reliable operation, strongly sealed 3) Tightness of seal is adjustable 2. Technical Parameters: 1) Air Pressure: 0.5Mpa Air Consumption: 10L/min 2) Aluminium clip type: 74U big / 7

The SEAL PACK FM-2202B rotary tub or cup filler and sealer can be used for liquids, viscous products, creams, powders or granules, depending on your specific need. Some videos are available online on http://www.youtube.com/user/D20400077#p/u/0/WpFz9znP3aU Technical Details Max Speed: 2,400 cups/hr (Product and Tub Size Dependent) Air Consumption: 200L/min Power Supply: 200L/min Control
