Metal Detectors

X-ray Inspection System Long life model[XR75 series] Anritsu x-ray systems provide missing product detection, shape detection, virtual weight, count and package check, etc. Detection area: 240/160mm x 120mm Model: KXS7522AWCLE X-ray output: Tube voltage 30 to 80 kV, tube current 0.4 to 3.3 mA, output 12 to 100 W Safety: X-ray leakage maximum 1.0 μSv/h or less, prevention of x-ray leakage by safet

Features: Includes control box that houses all the wiring Make: Mettler Toledo Model: Safeline Metal detection Aperture: 350mm L x 170mm H x 330mm deep Electrics: 100-240VAC, 50/60Hz, 340W max. Head only dimensions: 900mm L x 350mm W x 450mm H

The Thermo Scientific EZx is a conveyorized X-ray system designed to look and work more like a metal detector than a complex X-ray system. It utilizes a unique wrap around detector that assures there are never any “blind spots” in the inspection tunnel. The exceptionally reliable, wide beam X-ray source can easily penetrate most packaged foods without any trouble. The EZx contaminant detection sys

Anritsu vertical model is suitable for tall products in containers, such as beverages and seasonings in glass and plastic bottles. - Max Product Weight: 5Kg - Product Size: 80 W x 280 H mm - Temp: 0-40 degree Celsius - Power: 100 VAC-240VAC - 1~ 1510VA 50/60Hz - Aperture: 100mm W x 280mm H x 170mm deep - Rejecter type: High pressure pneumatic blower - VSD for speed control: Keyence Hyb

Aperture Size: 9.5 inch Dia x 800mm Long - Single phase digital controls, - Stainless steel frame, - Complete with an electro pneumatic rejection station Sensitivity as per results from test in-house: 1.5mm Ferrous, 2mm Non-Ferrous and 2mm Stainless Steel - Manual available

- Superior detection capability of magnetic, non-magnetic and stainless steel metal contaminants - Very effective compensation of product effect - FDA Title 21CFR Part 11 Compliant: Data Security; Data Integrity; Data Traceability - Rugged AISI 316L stainless steel construction and food compatible plastic parts (EU, FDA compliant) - Superior washdown construction with optimal cleanability and

Aperture size; 350 mm wide, 650 mm high. SCADA protocols Modbus RTU via RS-485, and an RS-232 interface. Scanning speed range from 1 m/min (3.1 ft/min) up to a maximum of 350 m/min (1000 ft/min) (dependent on configuration). Note: They are pulled apart and need to be reassembled. Metal Detector Unit Full Stainless Steel Construction on 4 hard stand Dimensions: 370mm (L) x 700mm (W)

Stainless steel frame with emergency stop button and bell alarm. Electrics: 1~, 240VAC, 50hz, 3 pin plug Metal Detector: - S/N: 21272 - CAP: 100VA - Input: 100V, 1~ - TYP: MP2-400A - Detector Unit: B250 , S/N 318 Detection Coil: - B type - Opposing type - High frequency type - Best for dry product - Splt-off to 4 pieces, and adjustable the effective height by liner block. - E

This ANRITSU Model X-RAY Inspection Machine is designed especially for Pharmaceutical Products. Detection Area Maximum Width: 100 mm Maximum Height: 30 mm Speed: 10-40/ meters min Maximum: 0.5kg Pdf attached

Aperture Size: 250 W x 120 H mm Belt Dimensions: 1,500 L x 200 W x 860 H mm Painted Construction Stainless Steel Frame Sew Motor + Gearbox Calibration Date: 13/03/18 Power: 3-Phase, 415V, 50Hz, 10Amp 0.25kW

The KD7305ABW is used to detect contaminants in products, such as meat, fish, etc., when X-ray leakage prevention curtains cannot be used. Features: 1. Short length (1570 mm) 2. Less than 1 µSv/h X-ray leakage (without X-ray leakage prevention curtains) 3. IP66-compliant conveyor 4. 50-mm detection height and 240-mm detection width (KD7305ABW)

The KD7305ABW is used to detect contaminants in unpackaged bulk products, such as meat, fish, etc., when X-ray leakage prevention curtains cannot be used. Features: 1. Short length (1570 mm) 2. Less than 1 µSv/h X-ray leakage (without X-ray leakage prevention curtains) 3. IP66-compliant conveyor 4. 50-mm detection height and 240-mm detection width (KD7305ABW)

Product Weight: 5 kg Max (50 m/min) Prod Size: 240 mm W x 30 mm H Temp: 0 deg C - 35 deg C

Anritsu X-ray foreign body detection machine for the detection of products mixed with small foreign objects, such as metal, sand, stone, shell, glass, pearls and high-density plastic . 15-inch color touch screen for customers of the simple operation of the screen, with the production of sensitivity adjustment and automatic tracking function, the new information management and maintenance functions

Technical Specifications : Pipe Diameter: 75mm ID Single Phase, 220V, 50Hz Touch screen panel control All s/s mobile on trolley

PROUDLY AUSTRALIAN MADE! This vertical fall or drop through metal detector is commonly used on Form Fill and Seal machines, mounted just above the forming tube, or in other applications for gravity fed free flowing powders, pipeline, liquid or granular materials. SPECIFICATIONS : Detector Head weight: 200mm unit is 28kg Detection Sensitivity at Phase Out: 200mm unit is 1.6mm mild steel & 2.

PROUDLY AUSTRALIAN MADE! This vertical fall or drop through metal detector is commonly used on Form Fill and Seal machines, mounted just above the forming tube, or in other applications for gravity fed free flowing powders, pipeline, liquid or granular materials. These drop-through metal detectors are suitable for dry products, and not intended for fresh products and wet environment. SPECIF

PROUDLY AUSTRALIAN MADE! This vertical fall or drop through metal detector is commonly used on Form Fill and Seal machines, mounted just above the forming tube, or in other applications for gravity fed free flowing powders, pipeline, liquid or granular materials. These drop-through metal detectors are suitable for dry products, and not intended for fresh products and wet environment. SPECIF

This s/s framed metal detection unit was used in a confectionery plant. Aperture: 130mm H x 240mm belt (300mm W overall )Detects 1.2 fe & 2.00 s/s in dry products. Belt speed 21mm Height above ground: 870mm Reject Mechanism: Air Blast Electrics: 240AC, 25VA Mobile - castors fitted with height adjustment
